Description
Technical features:
1.Low energy consumption, stable performance, strong adaptability, fast gas production, adjustable yield and purity;
2.Integrated skid structure design, easy installation and operation, small land occupation;
3.Simple operation, intelligent control, and unmanned operation can be realized;
4.Special compression protection device to prolong the service life of zeolite molecular sieve;
5.Pneumatic valves of international famous brands are adopted to ensure the continuous operation of the equipment;
6.Various fault diagnosis, alarm and processing functions;
7.Optional touch screen man-machine interface, adaptive energy-saving control, dew point detection, DCS communication, etc
| Model | Capacity (Nm3/h) | Purity (%) | Dimensions(mm) LxWxH | Filling speed/24hours | Capacity (Nm3/h) | Purity (%) | Dimensions(mm) LxWxH |
| ZRO-3 | 3 | 90-95 | 1200X1200X1800 | 12 bottles | 3 | 97±1 | 5500X1200X2000 |
| ZRO-5 | 5 | 90-95 | 1200X1200X2000 | 20 bottles | 5 | 97±1 | 6000X1500X2150 |
| ZRO-10 | 10 | 90-95 | 1600X1500X2150 | 40 bottles | 10 | 97±1 | 7000X1700X2550 |
| ZRO-20 | 20 | 90-95 | 1800X1700X2550 | 80 bottles | 20 | 97±1 | 7500X1700X2600 |
| ZRO-30 | 30 | 90-95 | 1900X1700X2600 | 120bottles | 30 | 97±1 | 8000X1900X2750 |
| ZRO-50 | 50 | 90-95 | 2100X2000X2750 | 200bottles | 50 | 97±1 | 8500X2000X3200 |
| ZRO-100 | 100 | 90-95 | 5500X1550X3200 | 400bottles | 60 | 97±1 | 9500X2100X3200 |
| ZRO-150 | 150 | 90-95 | 6000X1800X3500 | 600bottles | 80 | 97±1 | 12000X2200X3200 |
| ZRO-200 | 200 | 90-95 | 6600X2000X3700 | 800bottles | 100 | 97±1 | 15000X2600X3500 |
