  • industrial oil free diaphragm carbon dioxide compressor extraction
  • industrial oil free diaphragm carbon dioxide compressor extraction
  • industrial oil free diaphragm carbon dioxide compressor extraction
  • industrial oil free diaphragm carbon dioxide compressor extraction
industrial oil free diaphragm carbon dioxide compressor extraction industrial oil free diaphragm carbon dioxide compressor extraction industrial oil free diaphragm carbon dioxide compressor extraction industrial oil free diaphragm carbon dioxide compressor extraction

industrial oil free diaphragm carbon dioxide compressor extraction

  • Product Item:GD4-190/16-300
  • silent working and easy moving
  • 24hours heavy duty working model
  • CE and iso 9001
  • two years quality guarantee
  • industrial oil free diaphragm carbon dioxide compressor extraction
    Online Inquiry Send Email

    Description

    oil free diaphragm carbon dioxide compressor , is a reciprocating compressor that reciprocates in a cylinder to compress and transport gas.
    The cylinder filling diaphragm nitrogen compressor is a special type of volumetric compressor with large compression ratio, good sealing performance, and the compressed gas is not polluted by lubricating oil and other solid impurities. Therefore, it is suitable for compressing high purity, rare and precious, flammable, explosive, toxic and harmful, corrosive and high pressure gases.

    piston carbon dioxide diaphragm compressor, are one of many types of compressors. It has a special name because it has a special diaphragm that separates the compressed medium from the outside. The diaphragm compressor can also be referred to simply as a membrane compressor. Due to its special structure, the oxygen reciprocating low pressure diaphragm compressor does not need lubrication, and the sealing performance is very good. The compressed medium is not in contact with any slip agent, so it can compress the gas with very high purity, generally achieving a purity of 99.999%, which is more suitable for compression. And transport all kinds of precious rare gases. In addition, for corrosive, radioactive, toxic, and explosive gases, diaphragm compressors are also particularly suitable. The diaphragm compressor has good heat dissipation and can adopt a high compression ratio, so its pressure range is wide, and the exhaust pressure can be up to 500MPa. It is used in the food industry, petroleum industry chemical industry, electronics industry, nuclear power plant, aerospace, military equipment, medicine, scientific research and other fields.

    G4 oil free carbon dioxide diaphragm compressor for industrial   |nitrogen compressor|is a non-standard compressor product, G4 diaphragm compressor is divided into single cylinder GZ4and double cylinder GL4 and GD4 diaphragm compressor, G4 diaphragm compressor piston force 8TON, Customized according to different customer parameters, requirements and environment!
    GZ4 oil free cylinder filling diaphragm nitrogen compressor is composed of cylinder block, cylinder head, crankshaft connecting rod, diaphragm, oil circuit, gas path, water cooling system and motor drive. The G4 and G4 diaphragm compressor series products are available from our company. Cooling method: air cooling and water cooling.
    Company product features
    Ø Advanced oil-free disc cylinder component structure reduces the difficulty of assembly process; reduces sealing surface; alarm when leakage medium leaks, improves the reliability of the whole machine.
    Ø The oil consumption of the whole machine hydraulic oil is small, which is 1/2 of the oil used in the traditional diaphragm compressor. The economic advantage is very obvious for the oxygen compressor.
    Ø New membrane cavity curve, Kezan
    Nie or HOERBIGER's air valve,
    Leading diaphragm surface treatment technology
    Improves the work of the compressor
    Efficiency, achieving high energy efficiency,
    Moreover, the life of the vulnerable piece diaphragm and the air valve is improved. Diaphragm and air valve have a guaranteed average life of 3000
    Hours and 6,000 hours or more.
    Ø Full-featured built-in oil supply and pressure regulation system for compressor lubrication and oil
    Cylinder work provides pressure stable, clean quality lubricants and oils
    The road system does not leak, completely different from the traditional diaphragm compressor oil system.
    It belongs to our company's patented technology.
    Ø User-friendly instrument interface and middle window, simple oil and gas pipeline.

    Characteristics of G4 series oil free diaphragm carbon dioxide compressor
    Compact structure, is a large diaphragm compressor
    Structure type, D type (two cylinder, three cylinder or four cylinder)
    Lubrication method
    Replenishment method
    Cooling method, water cooling
    Repair single piece maximum weight: 2500kg
    Maximum maintenance space: no less than 1.5 meters around

    Model Flow Rate Nm3/hr Suction Pressure .Mpa Discharge pressure.Mpa Water Consumption L/hr Speed .rpm Motor.KW Dimension L*W*H mm Weight kgs
    GD4-90/200 90 常压 20 4000 400 45 3800x2800X1650 12.8
    GD4-100/160 100 常压 16 4000 400 45 3800X2800X1650 12.8
    GD4-240/6-150 240 0.6 15 6500 400 75 3500X2300X1600 8.6
    GD4-190/16-300 190 1.6 30 5000 3600 55 3500X2300X1500 7.8
    GD4-400/12-210 400 1.2 21 6500 400 75 3500X2300X1600 8.6
    GD4-600/12-40 600 1.2 4 5000 360 55 3500X2300X1600 8.6
    GD4-360/15-210 360 1.5 21 6500 400 75 3500X2300X1600 8.6
    GD4-400/8-110 400 0.8 11 6700 400 55 3500X2300X1600 8.9
    GD4-140/14-500 140 1.4 50 6000 400 75 3500X2300X1500 7.8
    GD4-200/4-160 200 0.4 16 6500 400 75 3500X2300X1600 8.6
    GD4-300/4.5-140 300 0.45 14 6000 400 75 3500X2300X1600 8.5
    GD4-450/11-100 450 1.1 10 6500 400 75 3500X2300X1600 8.5
    GD4-1000/14-50 1000 1.4 5 6500 400 75 3500X2300X1600 8.2
    GD4-300/0. 11-6 300 0.011 0.6 4000 420 45 3800X3200X1900 13
    GD4-180/2-200 180 0.2 20 6500 400 75 3500X2300X1600 8.6
    GD4-600/15-350 600 1.5 35 12000 400 160 4000X2400X2000 9.8
    GD4-1000/7-150 1000 0.7 15 18000 400 200 4000X2400X2000 10.6
    GD4-7340/66—87 7340 6.6 8.8 8000 420 110 3500X2800X1900 9.8
