Description
TOPLONG Oil-Free Variable Frequency Screw Compressor
◎ Constant pressure control: high-precision constant pressure control with a pressure fluctuation range within0.01 MPa;
◎ Variable frequency soft start: remove peak current during starting, avoid the power grid impact, prevent the current impact through gradual speed regulation and improve flexibility;
◎ No idling： prevent Idling of the compressor during running and reduce Invalid energy consumption；
© High performance vector control: low-frequency starting provides a large torque and a low running current,
ensuring to get a reasonable torque to drive the air compressor to run stably with the minimum temperature rise
◎ Constant pressure control: high-precision constant pressure control with a pressure fluctuation range within0.01 MPa;
◎ Variable frequency soft start: remove peak current during starting, avoid the power grid impact, prevent the current impact through gradual speed regulation and improve flexibility;
◎ No idling： prevent Idling of the compressor during running and reduce Invalid energy consumption；
© High performance vector control: low-frequency starting provides a large torque and a low running current,
ensuring to get a reasonable torque to drive the air compressor to run stably with the minimum temperature rise
of the motor within a wide speed range;
TOPLONG Permanent Magnet Variable Frequency Screw Compressor
◎ Constant pressure control: high-pfedsion constant pressife control with a pressure fluduaiion range within 0.01 MPa;
◎ Variable frequency/ soft start: remove peak current during starting, avoid the power grid impact, prevent the
current impact through gradual speed regulation and improve flexibility;
◎ No idling: prevent idling of the compressor during running and reduce invalid energy consumption;
The permanent magnet motor adopts a high-efficiency rare earth magnet, without loss of excitation at 180,
providing a long service life and saving about 6%~7% more energy than an ordinary variable frequency motor;
Obtain the maximum efficiency within a wider range to make th© air compressor more energy-efficient.
| model | Maxlnmum work pressure MPa | AAD m8/min | Motor power kw | noise dB | PpedamsM oACoolIng waterinlet and outlet | QLMntityoA cooing witer | Lubricating water L | dimension | weight kg | Air outlet |
| 32P Water vntvrlnoSZ^ T/H | LxWxH mm | |||||||||
| GW06VA/W | 0.8 | 0.3-0.78 | 5.5 | 57 | 3/4" | 1.5 | 10 | 800x800x1100 | 460 | 3/4'' |
| 1.0 | 0.2^0.65 | |||||||||
| GW08VA/W | 0.8 | 0.35~1.17 | 7.5 | 57 | 3/4" | 2 | 10 | 800x800x1100 | 510 | 3/4'' |
| 1.0 | 0.3-1.05 | |||||||||
| 1.25 | 0.24-0.81 | |||||||||
| GW11VA/W | 0.8 | 0.545.72 | 11 | 60 | 1'' | 2.5 | 26 | 1200x760x1300 | 620 | 3/4'' |
| 1.0 | 0.45^1.42 | |||||||||
| 1.25 | 0.35-1.10 | |||||||||
| GW15VA/W | 0.8 | 0.75-2.43 | 15 | 60 | 1'' | 3.5 | 26 | 1200x760x1300 | 670 | 3/4'' |
| 1.0 | 0.65-2.17 | |||||||||
| 1.25 | 0.6^1.80 | |||||||||
| GW18VA/W | 0.8 | 0.9-3.13 | 18.5 | 63 | 1'' | 4 | ||||
| 1.0 | 0.9-2.82 | 30 | 1400x900x1450 | 730 | 1" | |||||
| 1.25 | 0.6-2.05 | |||||||||
| GW22VA/W | 0.8 | 1.1~3.62 | 22 | 63 | 1'' | 5 | 30 | 1400x900x1450 | 780 | 1" |
| 1.0 | 0.97~3.21 | |||||||||
| 1.25 | 0.85-2.78 | |||||||||
| 0.8 | 1.55-5.12 | 30 | 66 | 1 1/2'' | 7 | 40 | 1150 | 1 1/4'' | ||
| GW30VA/W | 1.0 | 1.255^-4.43 | 1550x1150x1500(A) | |||||||
| 1.25 | 1.1~3.63 | 1500x1150x1300(W) | ||||||||
| GW37VA/W | 0.8 | 1.91-6.30 | 37 | 66 | 1 1/2'' | 9 | 40 | 1200 | 1 1/4'' | |
| 1.0 | 1.60-5.33 | 1550x1150x1500(A) | ||||||||
| 1.25 | 1.42-4.77 | 1500x1150x1300(W) | ||||||||
| GW45VW | 0.8 | 2.50~7.8 | 45 | 68 | 1 1/2'' | 10 | 90 | 1490 | 2" | |
| 1.0 | 1.91-6.30 | 1800x1300x1750(A) | ||||||||
| 1.25 | 1.70-5.56 | 1800x1300x1680(W) | ||||||||
| GW55VW | 0.8 | 3.0-9.76 | 55 | 69 | 1 1/2'' | 12 | 100 | 1980x1300x1750(A) 1800x1300x1680(W) | 1570 | 2" |
| 1.0 1.25 | 2.60-8.55 2.30~7.67 | |||||||||
| GW75VW | 0.8 | 3.95-13.00 | 75 | 72 | 1 1/2'' | 18 | 100 | 1800x1300x1750 | 1750 | 2" |
| 1.0 | 3.40-11.50 | |||||||||
| 1.25 | 3.0-9.70 | |||||||||
| GW90VW | 0.8 | 5.0~16.60 | 90 | 73 | 1 1/2'' | 20 | 120 | 2200x1550x1800 | 2450 | 2 1/2'' |
| 1.0 | 4.30^14.66 | |||||||||
| 1.25 | 3.72-12.60 | |||||||||
| GW110VW | 0.8 | 6.0-19.97 | 110 | 77 | 2'' | 24 | 120 | 2200x1550x1800 | 2580 | 2 1/2'' |
| 1.0 | 5.0~16.66 | |||||||||
| 1.25 | 4.65^15.56 | |||||||||
| GW132VW | 0.8 | 6.75-22.52 | 132 | 77 | 2'' | 30 | 120 | 2200x1550x1800 | 2700 | 2 1/2'' |
| 1.0 | 6.0-19.97 | |||||||||
| 1.25 | 5.07^16.90 | |||||||||
| GW160VW | 0.8 | 8.5~28.11 | 160 | 79 | 3'' | 35 | 160 | 3000x1800x2100 | 3900 | 3" |
| 1.0 | 7.6~25.45 | |||||||||
| 1.25 | 6.7-22.52 | |||||||||
| GW185VW | 0.8 | 10-33.97 | 185 | 79 | 3'' | 38 | 160 | 3000x1800x2100 | 4050 | 3" |
| 1.0 | 8.72-29.00 | |||||||||
| 1.25 | 7.75^25.21 | |||||||||
| GW200VW | 0.8 | 11.2-36.75 | 200 | 80 | 4'' | 42 | 200 | 3100x1850x2100 | 4200 | 4" |
| 1.0 | 9.68-32.78 | |||||||||
| 1.25 | 9.2~29.24 | |||||||||
| GW220VW | 0.8 | 12.2-39.67 | 220 | 80 | 4'' | 47 | 200 | 3100x1850x2100 | 4400 | 4" |
| 1.0 | 11.2^36.75 | |||||||||
| 1.25 | 9.0-29.63 | |||||||||
| GW250VW | 0.8 | 13.5-44.78 | 250 | 80 | 4'' | 53 | 200 | 3100x1850x2100 | 4800 | 4" |
| 1.0 | 12.3^39.67 | |||||||||
| 1.25 | 10.2 〜33.97 |
