Description
tank nitrogen compressor parameters:
1. Principle: Oil-free reciprocating piston
2. Cooling type: air or water cooling
3. Power consumption: ≤55kw
4. Speed: 300-560rpm
5. Flow rate: ≤1000Nm3/h
6. Inspiratory pressure: 0-0.5Mpa
7. Exhaust pressure: ≤30Mpa
8. Compression level: 1-4
Main features of high pressure nitrogen booster compressor for nitrogen generator products:
All oil-free lubrication is clean and non-polluting.
High efficiency and low energy consumption.
High reliability, continuous operation for 24 hours.
The unit is air-cooled or water-cooled to reduce installation costs.
Compact structure, low operating and maintenance costs.
nitrogen compressor for tank cylinder filling parameters:
| Model 型号 | Working medium 工作介质 | suction pressure 进气压力(Mpa,Psig) | Discharge pressure 排气压力(Mpa,Psig) | Motor.KW 电机功率 | Flow rate Nm3/hr 流量 | Voltage 电源电压 | Cooling way 冷却方式 |
| GSW-50/6-150 | nitrogen | 0.6,85 | 15,2150 | 18.5 | 50 | 220V/380V/415V/440V 50/60HZ | water cooling |
| GSW-50/6-200 | nitrogen | 0.6,85 | 20,2875 | 18.5 | 50 | 220V/380V/415V/440V 50/60HZ | water cooling |
| GSW-60/3-150 | nitrogen | 0.3,43 | 15,2150 | 18.5 | 60 | 220V/380V/415V/440V 50/60HZ | water cooling |
| GSW-60/6-150 | nitrogen | 0.6,85 | 15,2150 | 18.5 | 60 | 220V/380V/415V/440V 50/60HZ | water cooling |
| GSW-60/7-140 | nitrogen | 0.7,100 | 14,2012 | 18.5 | 60 | 220V/380V/415V/440V 50/60HZ | water cooling |
| GSW-75/5.5-100 | nitrogen | 0.55,80 | 10,1437 | 18.5 | 75 | 220V/380V/415V/440V 50/60HZ | water cooling |
| GSW-90/0.75-100 | nitrogen | 0.075,11 | 10,1437 | 30 | 90 | 220V/380V/415V/440V 50/60HZ | water cooling |
| GSW-90/4-200 | nitrogen | 0.4,57 | 20,2875 | 30 | 90 | 220V/380V/415V/440V 50/60HZ | water cooling |
| GSW-102/10-150 | nitrogen | 1,145 | 15,2150 | 22 | 102 | 220V/380V/415V/440V 50/60HZ | water cooling |
| GSW-125/5-125 | nitrogen | 0.5,72 | 12.5,1800 | 30 | 125 | 220V/380V/415V/440V 50/60HZ | water cooling |
Kinly note ,if you have high pressure nitrogen booster compressor for nitrogen generator demand please tell us follows information when you send inquiry:
*Compressor working medium:
If single gas ,how many purity ? if mixed gas , what’s gas content lit ?
*Suction pressure(gauge pressure): barg
*Exhaust pressure(gauge pressure): barg
*Flow rate per hour for compressor: (Nm3/hr):
Compressor gas suction temperature ?
Compressor working hours per day : hours
Compressor working site altitude : m
Environment temperature ℃:
low three phase voltage and frequency :
